COR 70 Industrial
The COR 70 Industrial window system with hinges is designed to meet the needs of a specific market segment by offering an economical, simple, and versatile joinery solution with high performance. Developed by the R&D&I Department, this system adapts to various climatic conditions and energy efficiency requirements, making it suitable for a wide range of applications.
Technical Specifications
Maximum Dimensions:
Width (L): 1500 mm
Height (H): 2600 mm
Maximum Weight: 160 Kg
Installation Depth: 70 mm
Frame Thickness: 70 mm
Thermal Transfer Coefficient: 0.9 W/m²K
Glazing Thickness: Up to 55 mm
Features and Benefits
Versatile Design
The system offers the option to use straight or rounded glazing beads, allowing for aesthetic flexibility. It also supports the use of hidden hinge hardware, contributing to a sleek, modern look.
High Performance
TThe COR 70 Industrial system provides excellent thermal and acoustic performance, with a thermal transfer coefficient of just 0.9 W/m²K. This efficiency makes it ideal for varying climatic conditions and energy-saving requirements.
Easy Installation
The simple installation process and reduced labor requirements enable industrial production, saving time and costs. This ease of assembly ensures efficiency and scalability for large projects.
Enhanced Security
The system allows for the use of Evo Security hardware, providing enhanced safety features. This option ensures that the window system meets high security standards, making it a reliable choice for both residential and commercial applications.
Robust Construction
With a maximum width of 1500 mm, a height of 2600 mm, and the capability to support up to 160 kg, the COR 70 Industrial system is designed for durability and robustness, ensuring long-lasting performance and stability.
Energy-Efficient Glazing
The ability to accommodate glazing up to 55 mm thick allows for the use of energy-efficient glass and thicker panes, further enhancing the system’s thermal and acoustic properties.
The COR 70 Industrial window system combines simplicity, versatility, and high performance, making it an ideal choice for various applications requiring economical yet effective joinery solutions.
